Monday, September 18, 2017

Quick Guide to User-Defined Types in Oracle PL/SQL

A Twitter follower recently asked for more information on user-defined types in the PL/SQL language, and I figured the best way to answer is to offer up this blog post.

PL/SQL is a strongly-typed language. Before you can work with a variable or constant, it must be declared with a type (yes, PL/SQL also supports lots of implicit conversions from one type to another, but still, everything must be declared with a type).

PL/SQL offers a wide array of pre-defined data types, both in the language natively (such as VARCHAR2, PLS_INTEGER, BOOLEAN, etc.) and in a variety of supplied packages (e.g., the NUMBER_TABLE collection type in the DBMS_SQL package).

Data types in PL/SQL can be scalars, such as strings and numbers, or composite (consisting of one or more scalars), such as record types, collection types and object types.

You can't really declare your own "user-defined" scalars, though you can define subtypes from those scalars, which can be very helpful from the perspective of maintaibilty and readability of code.

Here's an example:

DECLARE
   SUBTYPE currency_t is NUMBER (10,2);
   l_salary currency_t;
BEGIN
   l_salary := 10.50607;
   dbms_output.put_line (l_salary);
END;

10.51

You can, however, certainly define your own composite types. The phrase "user-defined types" often refers to object-oriented structures, but as you will see below, you the user can define your own types of:
  • Records (kinda like a row in a table, though usually consisting of a subset of the columns of a row)
  • Collections (similar to arrays in other programming languages)
  • Object types (comparable to classes in object-oriented languages)
User-Defined Record Types

You can very easily define records based on existing structures, such as a table or cursor. Sometimes, though, you will want to define your own record type to group together related elements or return multiple pieces of information from a function.

You can do this by defining your own record. Here's an example of a record type used as the return type of a function:

CREATE OR REPLACE PACKAGE comp_pkg
   AUTHID DEFINER
IS
   TYPE compensation_rt IS RECORD
   (
      salcomp        employees.salary%TYPE,
      total_salary   NUMBER
   );

   FUNCTION comp_info (emp_id_in IN employees.employee_id%TYPE)
      RETURN compensation_rt;
END;
/

CREATE OR REPLACE PACKAGE BODY comp_pkg
IS
   FUNCTION comp_info (emp_id_in IN employees.employee_id%TYPE)
      RETURN compensation_rt
   IS
      l_comp   compensation_rt;
   BEGIN
      SELECT salary, salary + NVL (commission_pct, 0)
        INTO l_comp
        FROM employees
       WHERE employee_id = emp_id_in;

      RETURN l_comp;
   END;
END;
/

DECLARE
   l_comp   comp_pkg.compensation_rt;
BEGIN
   l_comp := comp_pkg.comp_info (101);
   DBMS_OUTPUT.put_line ('Total salary = ' || l_comp.total_salary);
END;
/

[Thanks to Gavin Zzw for several suggestions to improve the code above]

And here's an example of nesting one record type inside another. Normalizing my runtime data structures!

DECLARE
   TYPE phone_rectype IS RECORD
   (
      area_code    PLS_INTEGER,
      exchange     PLS_INTEGER,
      phn_number   PLS_INTEGER,
      extension    PLS_INTEGER
   );

   TYPE contact_rectype IS RECORD
   (
      day_phone#    phone_rectype,
      eve_phone#    phone_rectype,
      cell_phone#   phone_rectype
   );

   l_sales_rep   contact_rectype;
BEGIN
   /* Set the day phone # */
   l_sales_rep.day_phone#.area_code := 773;
   l_sales_rep.day_phone#.exchange := 426;
   l_sales_rep.day_phone#.phn_number := 9093;
   l_sales_rep.day_phone#.extension := NULL;

   /* Copy day phone to evening phone */
   l_sales_rep.eve_phone# := l_sales_rep.day_phone#;

   /* "Override" just phn_number field. */
   l_sales_rep.eve_phone#.phn_number := 2056;
END;

Since we can define records based on a table, view or cursor using the %ROWTYPE attribute, user-defined records do not proliferate in PL/SQL code.

When it comes to collections, though, we almost always declare our own types.

User-Defined Collection Types

Collections are the analogue of arrays in PL/SQL. There are three types of collections: associative arrays, nested tables, and arrays.

Collections come in very handy when you need temporary datasets in your program and do not want or need to rely on global temporary tables, SQL and the context switches between the PL/SQL and SQL engines. Collections are also the enabling technology for table functions, which are functions that are invoked in the FROM clause of a SELECT statement.

You can certainly take advantage of a variety of pre-defined collection types. In the following code fragment, for example, I grab the topics and difficulty levels of a set of Oracle Dev Gym workouts:

   l_topics         DBMS_SQL.number_table;
   l_difficulties   DBMS_SQL.number_table;
BEGIN
     SELECT topic_id, difficulty_id
       BULK COLLECT INTO l_topics, l_difficulties
       FROM dg_workouts
      WHERE goal_id = goal_id_in
   ORDER BY week_number;

The IDs are all integers, so why not use the DBMS_SQL collection? Actually, I suggest you do not do this. That's right. Don't do what I do. Do what I say. Why?

Because this is an example of "bad lazy." When someone comes along later to maintain my code, they will see my use of a DBMS_SQL element and wonder: "Where's the dynamic SQL?"

Our code should answer, not raise, questions. So what I should do is have my own table of numbers and use that. Funnily enough, I do. So I am going to fix my code right now to look this like:

   l_topics         qdb_numbers_nt;
   l_difficulties   qdb_numbers_nt;
BEGIN
     SELECT topic_id, difficulty_id
       BULK COLLECT INTO l_topics, l_difficulties
       FROM dg_workouts
      WHERE goal_id = goal_id_in
   ORDER BY week_number;

Ah....much better!

User-defined record types and collection types are often used together.

For example, in the code underlying the Oracle Dev Gym, the qdb_rankings package defines both a record type and collection type of those records:

/* The record type */

TYPE user_info_rt IS RECORD
(
   comp_event_id   INTEGER,
   total_seconds   INTEGER
);

/* Collection type; each element contains one of those records */
TYPE user_info_tt IS TABLE OF user_info_rt
   INDEX BY PLS_INTEGER;

/* A variable of that collection type */

l_user_timings  user_info_tt;

....

/* Now I populate the collection of records with a BULK COLLECT query */

SELECT comp_event_id, total_seconds
  BULK COLLECT INTO l_user_timings
  FROM mv_qdb_compev_answers eva
 WHERE     eva.competition_id = competition_id_in
       AND TRUNC (eva.start_date) BETWEEN start_in AND end_in
       AND eva.user_id = rec.user_id
       AND eva.pct_correct_answers = 100;

Collections are a lot of fun and very handy. Check out my Practically Perfect PL/SQL YouTube channel for hours of instruction on collections. And the PL/SQL doc offers extensive guidance on collections, as well.

User-Defined Object Types

Way back in Oracle8, object-oriented capabilities were added to Oracle Database, implemented in PL/SQL syntax. Instead of classes, they are called object types. And now, a number of big releases later, these object types support most of the features developers have come to expect from object-oriented languages including inheritance and dynamic polymorphism.

Here, for example, is a hierarchy of types to manage one of my all-time favorites things in the world: food.

CREATE TYPE food_t AS OBJECT
(
   name VARCHAR2 (100),
   food_group VARCHAR2 (100),
   grown_in VARCHAR2 (100),
   /* Generic foods cannot have a price, but we can
      insist that all subtypes DO implement a price
      function. */
   NOT INSTANTIABLE MEMBER FUNCTION price RETURN NUMBER
)
   NOT FINAL NOT INSTANTIABLE;
/

CREATE TYPE dessert_t UNDER food_t (
      contains_chocolate CHAR (1),
      year_created NUMBER (4),
      OVERRIDING MEMBER FUNCTION price RETURN NUMBER
   )
   NOT FINAL;
/

CREATE OR REPLACE TYPE BODY dessert_t
IS
   OVERRIDING MEMBER FUNCTION price RETURN NUMBER
   IS
      multiplier   NUMBER := 1;
   BEGIN
      DBMS_OUTPUT.put_line ('Dessert price!');

      IF self.contains_chocolate = 'Y'
      THEN
         multiplier := 2;
      END IF;

      IF self.year_created < 1900
      THEN
         multiplier := multiplier + 0.5;
      END IF;

      RETURN (10.00 * multiplier);
   END;
END;
/

CREATE TYPE cake_t UNDER dessert_t (
      diameter NUMBER,
      inscription VARCHAR2 (200),
      /* Inscription and diameter determine the price */
      OVERRIDING MEMBER FUNCTION price RETURN NUMBER
   );
/

CREATE OR REPLACE TYPE BODY cake_t
IS
   OVERRIDING MEMBER FUNCTION price
      RETURN NUMBER
   IS
   BEGIN
      DBMS_OUTPUT.put_line ('Cake price!');
      RETURN (5.00 + 0.25 * (LENGTH (self.inscription)) + 0.50 * diameter);
   END;
END;
/

DECLARE
   my_favorite_vegetable   food_t
      := food_t ('Brussel Sprouts', 'VEGETABLE', 'farm');
BEGIN
   p.l (my_favorite_vegetable.price);
END;
/

DECLARE
   last_resort_dessert   dessert_t
                            := dessert_t ('Jello',
                                          'PROTEIN',
                                          'bowl',
                                          'N',
                                          1887);
   heavenly_cake         cake_t
                            := cake_t ('Marzepan Delight',
                                       'CARBOHYDRATE',
                                       'bakery',
                                       'N',
                                       1634,
                                       8,
                                       'Happy Birthday!');
BEGIN
   DBMS_OUTPUT.put_line (last_resort_dessert.price);
   DBMS_OUTPUT.put_line (heavenly_cake.price);
END;
/

/* Demonstration of dynamic polymorphism */

DECLARE
   TYPE foodstuffs_nt IS TABLE OF food_t;

   fridge_contents   foodstuffs_nt
                        := foodstuffs_nt (dessert_t ('Strawberries and cream',
                                                     'FRUIT',
                                                     'Backyard',
                                                     'N',
                                                     2001),
                                          cake_t ('Chocolate Supreme',
                                                  'CARBOHYDATE',
                                                  'Kitchen',
                                                  'Y',
                                                  2001,
                                                  8,
                                                  'Happy Birthday, Veva'));
BEGIN
   FOR indx IN fridge_contents.FIRST .. fridge_contents.LAST
   LOOP
      DBMS_OUTPUT.put_line (
            'Price of '
         || fridge_contents (indx).name
         || ' = '
         || fridge_contents (indx).price);
   END LOOP;
END;
/

As you can see from the above example, Oracle Database supports substitutability with object types as well. The easiest way to understand this concept is:

Every cake is a dessert; every dessert is a food.
But of course not every food is a dessert, nor is every dessert a cake.

Take a look at that example of dynamic polymorphism. I declare a nested table of food_t, but I have no problem inserting a dessert and cake into the collection.

The same is true for relational tables. In the code below, I create a table whose single column is of type food_t. I then insert two rows into the table (a dessert and cake).

CREATE TABLE food_tab (food food_t)
/

DECLARE
   s_and_c    dessert_t
                 := dessert_t ('Strawberries and cream',
                               'FRUIT',
                               'Backyard',
                               'N',
                               2001);
   choc_sup   cake_t
                 := cake_t ('Chocolate Supreme',
                            'CARBOHYDATE',
                            'Kitchen',
                            'Y',
                            2001,
                            8,
                            'Happy Birthday, Veva');
BEGIN
   INSERT INTO food_tab
        VALUES (s_and_c);

   INSERT INTO food_tab
        VALUES (choc_sup);
END;
/

SELECT COUNT (*) FROM food_tab
/

2

I have heard from several developers who have used object types to implement applications within a comprehensive object-oriented framework. But it is rare. Most Oracle Database developers rely on the relational model of SQL and the procedural structure of PL/SQL to build their application backends.

There is, as I am sure you can imagine, lots more to learn about object types. If this approach intrigues you, check out the very useful Database Object-Relational Developer's Guide.

Well, there's your introduction to the different kinds of user-defined types in Oracle Database and PL/SQL. Did I leave anything important out? Let me know!

And here's a LiveSQL script that demonstrates all the object type-related functionality shown above.

Monday, September 11, 2017

Surgical strike on spaghetti code with CONTINUE statement

It can be incredibly painful to make changes to an existing program that has the markings of spaghetti code. And isn't it positively terrifying to make those changes when you don't have a regression test for the program that you can run afterward to ensure that no bugs were inadvertently introduced?

Yet that is what we are often called upon to do.

When faced with this situation, the smart thing to do is to make the smallest, most isolated change possible, thereby minimizing the ripple effect.

Suppose the code you have to modify looks like this:

PROCEDURE someone_elses_mess
/*
|| Author: Long-Gone Consultant
|| Maintained by: Terrified Employee
*/
IS
BEGIN
   ... lots and lots of convoluted code

   FOR index IN 1 .. my_collection.COUNT
   LOOP
      ... hard-to-understand logic here

      ... more of the same here

   END LOOP;
END;

and you need to add some code between "hard-to-understand logic here" and "more of the same here." If a certain condition is met, you want to execute some new code and then skip over the rest of the loop body and move on to the next iteration.

You can accomplish this in a few ways:
  • Adding an IF statement
  • Using a GOTO statement
  • Using a CONTINUE statement
Here's what the loop body might look like with an IF statement:

BEGIN
   ... lots and lots of convoluted code

   FOR index IN 1 .. my_collection.COUNT
   LOOP
      ... hard-to-understand logic here

      IF new_condition
      THEN
         ... new code here
      ELSE
         ... more of the same here
      END IF;
   END LOOP;
END;

Here's the approach with GOTO:

BEGIN
   ... lots and lots of convoluted code

   FOR index IN 1 .. my_collection.COUNT
   LOOP
      ... hard-to-understand logic here

      IF new_condition
      THEN
         ... new code here

         GOTO end_of_loop;
      END IF;

      ... more of the same here
      <<end_of_loop>>
      NULL; -- Placeholder
   END LOOP;
END;

And, finally, here's the approach with CONTINUE (new to Oracle Database 11g):

BEGIN
   ... lots and lots of convoluted code

   FOR index IN 1 .. my_collection.COUNT
   LOOP
      ... hard-to-understand logic here

      IF new_condition
      THEN
         ... new code here

         CONTINUE;
      END IF;

      ... more of the same here

   END LOOP;
END;

Now, with code this simple, all three of these approaches look reasonable and get the job done. But if you are dealing with an extremely complex, convoluted program, the IF statement gets tricky. You have to make sure you set up the ELSE clause properly and enclose the correct logic. Which means that you have to find the END LOOP statement for this loop, which could be hundreds of lines later in the program, with many other END LOOPs in between.

The GOTO allows you to simply branch to the end of the loop, but, again, you must find the end of that loop and then add both the label and the placeholder "NULL;" statement so that the GOTO has someplace executable to go.

No, the best solution to this problem is to simply tell the PL/SQL runtime that you want to continue with the loop execution, skipping the rest of the body for this iteration. Clean, simple, and declarative.

And, by the way, just as with the EXIT statement, you can use CONTINUE in a WHEN clause and also specify an END label (helpful with nested loops).

Here is an example of CONTINUE WHEN:

BEGIN
   ... lots and lots of convoluted code

   FOR index IN 1 .. my_collection.COUNT
   LOOP
      ... hard-to-understand logic here

      /* I want to execute this new logic and then "escape." */
      ... new code here

      CONTINUE WHEN new_condition;

      ... more of the same here

   END LOOP;
END;

The following block shows how you can skip not only the rest of the inner loop but also the outer loop by specifying a label with CONTINUE:

BEGIN
   <<outer_loop >>
   FOR o_index IN 1 .. my_collection.COUNT
   LOOP
      <<inner_loop>>
      FOR i_index
            IN your_collection.FIRST ..
                your_collection.LAST
      LOOP
         ... lots of code

         /* Skip the rest of this and the outer loop if condition is met. */
         CONTINUE outer_loop WHEN condition_is_met;

         ... more inner loop logic

      END LOOP inner_loop;

      ... more outer loop logic

   END LOOP outer_loop;
END;

So: you like CONTINUE, right? Nice, clear, easy-to-understand syntax and code structure. You'll start using it, right? Right!

In that case, the following resources may be of assistance:

The Oracle Dev Gym offers a number of quizzes on CONTINUE. Just head to the home page and search on "CONTINUE".

And here's a LiveSQL script that demonstrates CONTINUE, comparing it to using GOTOs and exceptions to achieve the same result (please don't!).

Note: Much of this content originally appeared in Oracle Magazine.

Monday, August 28, 2017

About the Date Literal in Oracle Database

I offered up a past blog post on Twitter today:



And I saw this reply:
I am unfamiliar with this magical expression: DATE '2016-10-31'. How is this being resolved when it doesn't match the NLS date format?
Which reminded me than many developers are not aware of the date Literal feature of both SQL andPL/SQL. So I figured I should give you all a bit more detail on the topic.

So you are likely familiar with string literals, like 'ABC' and q'[don't need two single quotes]'.  And who isn't aware of using pretty much all the time number literals, like 123 and 2e7?

Relatively few developers know that you can have a date literal, too (and timestamp literal and timestamp with local timezone literal and interval literals).

Literals of these types generally have the form:

TYPE string-literal

where TYPE is the name of the datatype and string-literal is, well, you get the idea. :-)

Here are some examples:

1. Date literal


DATE '2017-08-26'

2. Timestamp literal

TIMESTAMP '2017-08-26 09:26:50.124'

2. Interval literal

INTERVAL '100-4' YEAR(3) TO MONTH

So why does the date literal "work" even if it doesn't match the default date format for my session?

Because the date literal is defined as part of the ANSI SQL standard. It contains no time portion, and must be specified in exactly this format ('YYYY-MM-DD'). Sorry, that's just how it is.

Now that you know about the date literal, you can test your knowledge with a Dev Gym quiz (just search for "date literal").

You can also play around with it easily using this LiveSQL script.

Wednesday, August 23, 2017

Do you REALLY need that SQL to be dynamic?


Dynamic SQL means a SQL statement that is constructed, parsed and executed "dynamically" at run time (vs. "statically" at compile time).

It's very easy to write static SQL in PL/SQL program units (one of the great joys of working with this database programming language). It's also quite easy to implement dynamic SQL requirements in PL/SQL.

But that doesn't mean you should. The bottom line regarding dynamic SQL is:
Construct and execute SQL at runtime only when you have to.
There are several good reasons to avoid unnecessary dynamic SQL:
  1. Security: dynamic SQL opens up the door to SQL injection, which can lead to data corruption and the leaking of sensitive data.
  2. Performance: while the overhead of executing dynamic SQL has gone way down over the years, it is certainly still faster to use static SQL.
  3. Maintainability: the code you write to support dynamic SQL is more - literally more code - and harder to understand and maintain.
Sometimes the misuse of dynamic SQL is obvious. Consider the following:

CREATE OR REPLACE FUNCTION name_from_id (id_in IN INTEGER)
   RETURN VARCHAR2
   AUTHID DEFINER
IS
   l_the_name   the_table.the_name%TYPE;
BEGIN
   EXECUTE IMMEDIATE 'select the_name from the_table where id = ' || id_in
      INTO l_the_name;

   RETURN l_the_name;
END;
/

The developer apparently believed, however, that since the value of the ID can change, it needs to be concatenated to the SQL statement, so it's gotta be done dynamically. Ha! There's nothing dynamic about this query. It should be rewritten to:

CREATE OR REPLACE FUNCTION name_from_id (id_in IN INTEGER)
   RETURN VARCHAR2
   AUTHID DEFINER
IS
   l_the_name   the_table.the_name%TYPE;
BEGIN
   SELECT the_name
     INTO l_the_name
     FROM the_table
    WHERE id = id_in;

   RETURN l_the_name;
END;
/

Often, the need for dynamic SQL is compelling at first, but then disappears with a little bit of analysis. Consider this function:

CREATE OR REPLACE FUNCTION name_from_id (table_in   IN VARCHAR2,
                                         id_in      IN INTEGER)
   RETURN VARCHAR2
   AUTHID DEFINER
IS
   l_the_name   VARCHAR2 (32767);
BEGIN
   EXECUTE IMMEDIATE
      'select the_name from ' || table_in || ' where id = ' || id_in
      INTO l_the_name;

   RETURN l_the_name;
END;
/

Well, heck, if I don't know the table name till run time, I sure can't use a static SELECT statement, right? Of course, right!

So, first of all, if this code is really and truly necessary, you need to think about SQL injection.

1. Is the table name provided directly by the user? You should never allow user input to be stuffed directly into your dynamic statement. They could enter all sorts of nasty stuff.

2. Even if not passed directly from user fingertips to EXECUTE IMMEDIATE, you should use DBMS_ASSERT to make sure that the table name passed in is a valid DB object, as in:

CREATE OR REPLACE FUNCTION name_from_id (table_in   IN VARCHAR2,
                                         id_in      IN INTEGER)
   RETURN VARCHAR2
   AUTHID DEFINER
IS
   l_the_name   VARCHAR2 (32767);
BEGIN
   EXECUTE IMMEDIATE
      'select the_name from ' ||
         SYS.DBMS_ASSERT.sql_object_name (table_in) ||
      ' where id = :id'
      INTO l_the_name
      USING id_in;

   RETURN l_the_name;
END;
/

Great, so the function is less vulnerable than before to injection. But does it really need to be dynamic?

The only way to answer that question is to check and see where and how the function is used. I could do a text search through my code (via an editor like Sublime) or an object search (in SQL Developer). I could also use PL/Scope if I'd gathered identifier information across my code base.

Suppose after doing my analysis, I find that the function is called twice as follows:

l_name := name_from_id (table_in => 'TABLE1', id_in => l_id);

l_recent_name := name_from_id (table_in => 'TABLE2', id_in => l_most_recent_id);

OK, I could shrug and say "Yep, two different table names. I need to use dynamic SQL."

But that would be a mistake. What I should think and say is:

"What? Just two different tables? I don't need dynamic SQL for that. That's just laziness."

Instead I could do either of the following:
  1. Create two different functions.
  2. Change to static SQL inside the function.
Two Different Functions

Really, why not? It's so easy and fast to write PL/SQL functions that call SQL. Just change to:

CREATE OR REPLACE FUNCTION name_from_table1_id (id_in IN INTEGER)
   RETURN VARCHAR2
   AUTHID DEFINER
IS
   l_the_name table1.the_name%TYPE;
BEGIN
   SELECT the_name
     INTO l_the_name
     FROM table1
    WHERE id = id_in;

   RETURN l_the_name;
END;
/

CREATE OR REPLACE FUNCTION name_from_table2_id (id_in IN INTEGER)
   RETURN VARCHAR2
   AUTHID DEFINER
IS
   l_the_name table2.the_name%TYPE;
BEGIN
   SELECT the_name
     INTO l_the_name
     FROM table2
    WHERE id = id_in;

   RETURN l_the_name;
END;
/

One Function, No Dynamic SQL

So you don't want two, three many functions for the "same" functionality (get name for ID). Fine, keep them all in one subprogram, but move the conditional logic inside.

CREATE OR REPLACE FUNCTION name_from_id (table_in   IN VARCHAR2,
                                         id_in      IN INTEGER)
   RETURN VARCHAR2
   AUTHID DEFINER
IS
   l_the_name   VARCHAR2 (32767);
BEGIN
   CASE table_in
      WHEN 'TABLE1'
      THEN
         SELECT the_name
           INTO l_the_name
           FROM table1
          WHERE id = id_in;
      WHEN 'TABLE2'
      THEN
         SELECT the_name
           INTO l_the_name
           FROM table2
          WHERE id = id_in;
      ELSE
         raise_application_error (
            -20000,
            'name_from_id does not support fetching from ' || table_in);
   END CASE;

   RETURN l_the_name;
END;
/

Sure, sometimes you really do need to use EXECUTE IMMEDIATE and dynamic SQL. In those situations, make sure you minimize the attack surfaces for SQL injection. Make sure you've got strong exception handling and logging.

But do make certain that this extra "technical debt" is necessary. There's a good chance you can get by without dynamic SQL. If so, your users, your fellow developers and your manager will all thank you!

Thursday, August 17, 2017

Referencing package-level variables inside the package body

I received this question yesterday:
Is there a shortcut for referencing package variables in the package body? In Java, as an example, you can use the "this" keyword as a reference to the current object. This came about as I needed to create a copy of a package for debug purposes and realized I had to rename all the references to the package name within the package body.
Before I answer, let's look at an example of what Tony is talking about. I create a package specification and then a body with package-level variable (declared outside any subprogram of the package):

CREATE OR REPLACE PACKAGE pkg
   AUTHID DEFINER
IS
   PROCEDURE proc (n_in IN NUMBER);
END;
/

CREATE OR REPLACE PACKAGE BODY pkg
IS
   smallest   NUMBER;

   PROCEDURE proc (n_in IN NUMBER)
   IS
   BEGIN
      IF n_in < pkg.smallest
      THEN
         DBMS_OUTPUT.put_line ('too small');
      END IF;
   END;
END;
/

Notice the line in blue and bold. I reference the package level variable, qualified with the package name (the approach that Tony has taken).

But then when Tony changes the name of the package, so he also has to change the dot-qualified references within the package.

Can you use "this" syntax, as is available in Java? No. You will see this error when trying to compile the package body:

PLS-00201: identifier 'THIS.SMALLEST' must be declared

"this"-style syntax is used only with object types in Oracle Database (our object-oriented extensions to the relational model), in which case you use "SELF" to reference the current object type instance.

So what should Tony do? Here are his (and mine, and your) options:
  • Continue to dot qualify with the package name, and do a (careful, very careful) global search and replace of the old package name to new. Like I say: CAREFUL.
  • Remove the package name. You don't need it.
That's right. You don't need to qualify the reference to this variable. In other words, this version of he package body will compile just fine:

CREATE OR REPLACE PACKAGE BODY pkg
IS
   smallest   NUMBER;

   PROCEDURE proc (n_in IN NUMBER)
   IS
   BEGIN
      IF n_in < smallest
      THEN
         DBMS_OUTPUT.put_line ('too small');
      END IF;
   END;
END;
/

The compiler will try to resolve the reference to smallest inside proc. When that doesn't work, it will check the "next level up" in scope: the package body. Ah ha! There it is. And the body compiles.

Of course, this will not work as desired if you declare a variable or constant with the same name inside proc. The following version will also compile, but that reference to smaller inside proc will not refer to the package level variable.

CREATE OR REPLACE PACKAGE BODY pkg
IS
   smallest   NUMBER;

   PROCEDURE proc (n_in IN NUMBER)
   IS
      smallest NUMBER;
   BEGIN
      IF n_in < smallest
      THEN
         DBMS_OUTPUT.put_line ('too small');
      END IF;
   END;
END;
/

In this case, you must qualify the variable with the scope you mean. You could qualify with the subprogram (procedure) or package name, by the way:

CREATE OR REPLACE PACKAGE BODY pkg
IS
   smallest   NUMBER;

   PROCEDURE proc (n_in IN NUMBER)
   IS
      smallest NUMBER;
   BEGIN
      IF n_in < proc.smallest -- references procedure's smallest
      THEN

      IF n_in < pkg.smallest -- references package level smallest
      THEN
         DBMS_OUTPUT.put_line ('too small');
      END IF;
   END;
END;
/

Of course, best of all is to avoid declaring variables with the same names at different scopes. That can be confusing - and then requires the use of dot-qualification. Another approach, frequently used, is to use different naming conventions for variables of different scope. For example, I commonly use "g_" to indicate a global variable in a package, and "l_" for local variables.

So my version of the package body would look like:

CREATE OR REPLACE PACKAGE BODY pkg
IS
   g_smallest   NUMBER;

   PROCEDURE proc (n_in IN NUMBER)
   IS
      l_smallest NUMBER;
   BEGIN
      IF n_in < l_smallest -- references procedure's smallest
      THEN

      IF n_in < g_smallest -- references package level smallest
      THEN
         DBMS_OUTPUT.put_line ('too small');
      END IF;
   END;
END;
/

The most important thing is to be consistent in your approach so others (including the Future You) can more easily understand your code.

A final comment regarding dot-qualifying variable names: when you reference PL/SQL variables and constants inside SQL statements in your PL/SQL blocks, you should always qualify them with their scope names. Example:

CREATE OR REPLACE PACKAGE BODY pkg
IS
   g_smallest   NUMBER;

   PROCEDURE proc (n_in IN NUMBER)
   IS
      l_salary NUMBER;
   BEGIN
      SELECT salary INTO l_salary
        FROM employees e
       WHERE e.employee_id = proc.n_in;
   END;
END;
/

By doing this, you give more information to the compiler that it can use to reduce the times when a program unit needs to be invalidated and recompiled. In the above package body, if I did not qualify my reference to n_in inside the SELECT, adding a column named "n_in" will cause the package body to be set to INVALID.

And upon recompilation, well, that reference to "n_in" will now be to the column and not your variable. Not good. By fully qualifying the reference, however, the compiler knows (via fine-grained dependency management, added in 11.1) that there can be no confusion, and adding a column to the employees table could not possibly disrupt the current behavior of the package body.

Thursday, August 10, 2017

No subqueries allowed in materialized view? No problem!

Have you ever run into the following error when trying to create a materialized view?

ORA-22818: subquery expressions not allowed here

Yes, it is true: you cannot have a scalar subquery in the SQL statement used to create your materialized view. Here's an example of what won't work (note: I am not claiming this query makes any sense):

CREATE MATERIALIZED VIEW hr_demo_mv
AS
     SELECT employee_id,
            (SELECT MAX (hire_date)
               FROM employees ce) maxhd
       FROM employees t
/
ORA-22818: subquery expressions not allowed here
22818. 00000 -  "subquery expressions not allowed here"
*Cause:    An attempt was made to use a subquery expression where these
           are not supported.
*Action:   Rewrite the statement without the subquery expression.

Rewrite my query without the subquery expression? But I just spent an hour putting it all together. Works great. Gives me exactly the results I want and need. Rewrite it? ARGH.

Calm yourself. While it is true that you will need to "rewrite the statement" that you provide in your CREATE MATERIALIZED VIEW statement, you will not have to abandon your subqueries and all your hard work.

All you have to do is create a view with the subqueries, and then create your materialized view based on the view:

CREATE VIEW hr_demo_v
AS
     SELECT employee_id,
            (SELECT MAX (hire_date)
               FROM employees ce) maxhd
       FROM employees t
/

View HR_DEMO_V created.

CREATE MATERIALIZED VIEW hr_demo_mv
AS
     SELECT * FROM hr_demo_v
/

Materialized view HR_DEMO_MV created.

I recommend this approach (the materialized view is "nothing more" than a select from a view), even if your materialized view query does not contain a subquery or anything else that would preclude the materialized view from being created.

By taking this approach, you can change the contents of the materialized view with the next refresh by doing nothing more than changing the query (instead of dropping and re-creating the materialized view).

Tuesday, August 8, 2017

Tightening security in your PL/SQL code with 12c new features, part 2

Oracle Database 12c offers several enhancements to improve security in your PL/SQL program units. These features include:
  • Avoid privilege escalation: Use the INHERIT [ANY] PRIVILEGES privilege to make it impossible for a lower-privileged user to take advantage of a higher-privileged user via an invoker rights unit. I covered this topic here.
  • Code-based access control: fine-tune access to database objects inside program units by granting roles to program units (doc), rather than - or in addition to - roles granted to schemas. That's the topic for this post.
Note: Oracle Magazine also offers this content (both blog posts) in a single article here.

Securing your database – and properly restricting access to the data and data structures within your database – ranks at the very top of the "most important things to do" list when building applications.
The best way to avoid unintended access or actions is to apply the "least privilege" principle: give a user the smallest number of (and most narrowly defined) privileges on database objects and the data inside those objects.

Oracle Database has always offered a very robust security mechanism: you can only access objects you own or those to which you were granted access. Within a PL/SQL program unit, you can choose the definer rights model (a user executes your code with your privileges) or the invoker rights model (a user executes your code with their privileges).  But the granularity of this mechanism operates at the schema level, making it difficult to apply the "least privilege" principle.

With Oracle Database 12c, you can now restrict privileges as tightly as you would like, right down to the individual program unit, by granting roles to program units, and not just to schemas. I'll explore this feature for both definer rights and invoker rights program units.

First, with definer rights, suppose that the HR schema was initially granted just two privileges: CREATE SESSION and CREATE PROCEDURE. I could then compile the following procedure in HR:

CREATE OR REPLACE PROCEDURE create_table (
   table_name_in IN VARCHAR2)
   AUTHID DEFINER
IS
BEGIN
   EXECUTE IMMEDIATE
      'CREATE TABLE ' || table_name_in || '(n NUMBER)';
END;

But when I try to create a table using the procedure, I see an error:

CONNECT HR/*****

BEGIN
   create_table ('my_table');
END;
/

ERROR at line 1: ORA-01031: insufficient privileges

Prior to Oracle Database 12c, the only way that HR could use this procedure would be to grant the CREATE TABLE procedure to the schema itself. But this means that any program unit defined in HR could then create a table, which the Chief Security Officer finds unacceptable.

With Oracle Database 12c, however, I can take a much more fine-grained approach, by granting privileges to the procedure itself, and not its owning schema.

Here’s how:

1. Create a role from a schema with the authority to do so, and grant it the CREATE TABLE privilege.

CREATE ROLE create_table_role
/

GRANT CREATE TABLE TO create_table_role
/

2. Grant the role to the procedure. This can be done as SYSDBA. It can also be done from the HR schema, if the role is granted to HR with the admin option. Here’s the grant as SYSDBA:

GRANT create_table_role TO PROCEDURE hr.create_table
/

To grant from HR, first execute this as SYSDBA:

GRANT create_table_role TO hr WITH ADMIN OPTION
/

ALTER USER hr DEFAULT ROLE ALL EXCEPT create_table_role
/

Then execute the grant from HR:

GRANT create_table_role TO PROCEDURE create_table
/

And now I can execute the procedure and successfully create the table:

BEGIN
   create_table ('my_table');
END;
/

PL/SQL procedure successfully completed.

But if I try to create the table directly, I see the same, earlier privileges error:

CREATE TABLE my_table2 (n NUMBER)
/

ERROR at line 1: ORA-01031: insufficient privileges

The only way to create a table from the HR schema is by calling this one procedure: a very targeted assignment of privileges. Now let's take a look at using code-based access control with an invoker rights module.

With invoker rights, the privileges of the invoking schema are used to determine what the module will be allowed to do. I need to give users the ability to display non-confidential information about employees: namely, they can see employee names and emails, but not salary information.

I can do this by creating a view on top of the EMPLOYEES table and only granting SELECT on the view. But I can also achieve this effect through code based access control, thereby avoiding the need to create a view.

Here's the invoker rights procedure for displaying appropriate employee information, owned by HR, which also owns the employees table.

CREATE OR REPLACE PROCEDURE show_employees (department_id_in IN INTEGER)
   AUTHID CURRENT_USER
AS
BEGIN
   DBMS_OUTPUT.put_line (
      'Employees in Department ' || department_id_in);

   FOR rec IN (SELECT e.last_name, e.email FROM hr.employees e
                WHERE e.department_id = department_id_in
                ORDER BY e.last_name)
   LOOP
      DBMS_OUTPUT.put_line (rec.last_name || ' - ' || rec.email);
   END LOOP;
END;
/

I'll let everyone execute the procedure:

GRANT EXECUTE ON show_employees TO PUBLIC
/

No other schemas have been granted SELECT on employees, so if, for example, a user connected to the SCOTT schema tries to execute this procedure, she will see an error:

BEGIN
   hr.show_employees (10);
END:
/

ERROR at line 1:
ORA-00942: table or view does not exist

Prior to Oracle Database 12c, to get this to work, you would have to do one of the following:
  • Grant SELECT on this table to SCOTT, but that would give SCOTT access to confidential information.
  • Create a view on top of EMPLOYEES that does not include the confidential information, and then grant SELECT on that view to SCOTT.
With Oracle Database 12c and higher, I can instead create a role that has the SELECT privilege on the EMPLOYEES table, and then assign the role to just that single procedure. Assuming HR has the CREATE ROLE privilege, here are the steps:

CREATE ROLE view_employees_role
/

GRANT SELECT ON employees TO view_employees_role
/

GRANT view_employees_role TO PROCEDURE show_employees
/

BEGIN
   hr.show_employees (10);
END:
/

Employees in Department 10
Whalen – JWHALEN@MY_COMPANY.COM

Now users can access the employee information appropriate to them, but I have not provided any other opportunities to access the employees table. I have, in other words, kept the attack surface (the number of points through which an unauthorized user can try to get at the table) to a minimum.
